TEVAI Specifications
Tevai Condition Valuation Survey
AMD - Condition Valuation Survey, Nov 2017.
Builder: Chung Hwa Boat Building, Kaohsiung, Taiwan
Model: Lafitte 44
Designer: Robert Perry
Flag of Registry: United States- USCG Doc. No. 639427
Hull Shape: Displacement
Rig: Cutter
Year Build: 1980
Year placed in service: 1981
LOA: 44 ft 0 in
Beam: 12 ft 6 in
Maximum Draft: 6 ft 6 in
Displacement: 28,000 lbs
Total Power: 75 HP
Engine Brand: Yanmar
Year Built: 2006
Engine Model: 4jh3te s/n 16072
Engine Type: Inboard
Engine/Fuel Type: Diesel
Engine Hours: 1715 approx @ Oct 2018
Engine Power: 75 HP
Transmission ZF model 2-F30M s/n 31742N
Cutlass Bearing -new 2016
PYY dripless packing –new 2016
Auto prop -3 blade (2006) with spare fixed prop
Cruising Speed: 6 knots
Maximum Speed: 7.5 knots
Fresh Water Tanks: (106 Gallons)
Echo Tec 11 Gallons per hour water maker 12VDC ( new 2016)
Fuel Tanks: (130Gallons)
Kumma Hot water tank (110VAC and engine heat exchange) new 2016
Number of cabins: 2
Number of heads: 2
Max number of bunks: 7
See the included drawing which shows layout better than words. Aft cabin has settee/pilot berth, queen size berth, 2 hanging lockers and a separate companion way to cockpit. Two hanging lockers aft. Salon/galley has centerline companionway to deck. Salon is two steps down from galley and has U shaped settee port and settee starboard. Nav station is on galley level. Heads with showers are forward port and starboard aft. Forward vee stateroom has storage and hanging locker, fans, red and white lights and huge hatch for ventilation
- Marine Air Conditioner 10,000 BTU
- 2 wine racks
- 4 Opening Ports Plus 2 hatches
- Massive storage
- Separate companionway to deck
- “at sea” upholstery covers (New 2017)
- 2 sea berths w/lee cloth
- Nav station on galley level
- Force 10 Three Burner Propane Stove with Oven and Broiler (2014)
- Corian surfaces (new 2014)
- Double Stainless Steel Sink w/ Moen Spray faucet
- Sea Gul water filtration system
- Separate freezer and refrig boxes –total approx. 17 cu ft each with SeaFrost air/water cool units and digital control (new 2015)
- New propane system 2013, 2- 10 pound bottles ( we get 8-10 weeks per bottle)
- A Great Galley Arrangement Whether Dockside, At Anchor or Underway
- Galley safety belt and attachment rings
- Easy access to salon – so cook is not away from crew and guests
- AB (model 9.5 VL) RIB Inflatable Dingy
- 15hp 2009 Yamaha 2 cycle Motor (put in service 2013)
- CQR 60lb. with 300 ft. Chain Rode
- 30 Shore Power- 3 cords and various adapters
- Extra Lines
- Bimini, Dodger and enclosure /sunscreens Saltwater
- Saltwater Wash-down Pump to anchor and cockpit
- Cockpit Freshwater shower
- Inflatable /storable fenders ( new 2017 -$600) plus more
- Hull sprayed with Awlcraft in 2016
- Decks and deck house painted with Awlcraft in 2017
- Bottom – hand stripped to barrier coat, 2 coats of Interprotect 2000 applied 2014
- Never had teak decks
- SeaHawk 77 black bottom paint, Oct 2018
- 8 fans inside cabin
- Most interior lights converted to LED
- Winslow 6 person offshore liferaft ( New 2013, Certified until May 2019)- with PLB packing inside
- Ditchbag with appropriate contents
- Flares, smoke and dye signal ( needs some updating)
- Manuals for all systems
- Most spare parts have spare parts
- Necessary lubes and cleaners
- Magna BBQ grill with dedicated 6 pound propane bottle
- Hand Tool kits
- Corian Surfaces in Galley, Salon and heads (2015)
- Interior re- varnished 2014 and 2015
- MOB pole. Life ring, throw bag, strobe
- Custom bed spreads aft cabin (new 2017) and vee berth
- Bedding, pillows mattress covers,“at sea” covers for aft settee (new 2017)
- HP 3915 printer
- Fujitsu scanner
- Charts and guide books
- Charts from the Great Lakes thru the Caribbean and to Panama
- Galley and cookware
- Extensive offshore medical kit
- EarTec G 24 wireless head sets ( communication for docking &anchoring)
- Exclusions: owner personal art and dive equipment
- Raymarine “smart” auto pilot brain – with spare brain
- Raymarine mechanical TYPE II autopilot drive –with spare drive unit
- 3 independent GPS units : Raymarine RL70C plotter at navdesk and in cockpit, Simrad cp32 at Navdesk, Raymarine A series plotter in cockpit and repeats AIS info
- Standard Horizon Black Phantom VHF/hailer/foghorn/intercom with RAM mics, mounted cockpit and aft cabin
- Icom IC M710 SSB HF with Pactor PTC IIusb
- Raymarine, AT 60, Speed, Depth AWI and multi displays in cockpit and at nav desk
- ICOM - M402 VHF at nav desk
- Max Sea Navigation Software Package (need to transfer to new owner computer)
- Digital Yacht Class B AIS transponder and receiver (new 2013)
- 2-Sat 406 EPIRB / with built in GPS (one new 2017)
- Wave Wi-fi Booster antenna
- ICOM M-36 Floating Hand held VHF
- Main, Staysail and Headsail in good to very good condition.
- Stackpack with at anchor sunshade by Ullman Sails Trinidad ( 2015)
- Sparcraft Aluminum Double Spreader Keel Stepped Mast- alwgrip 2013
- Sparcraft Aluminum Boom alwgrip 2013
- 1x19 S/S Standing Rigging, Stalock-Type Compression Fittings Top and Bottom
- Braided Dacron Running Rigging (Replaced as Needed)
- (2) Lewmar 55 ST Primary Winches
- (1) Lewmar 30 CST Winch
- (4) Lewmar 40 ST Winches
- (3) Lewmar 40 Winches
- (1) Lewmar 22 Winch
- Harken Hydraulic Back stay adjuster –new 2013
- Spare mechanical backstay adjuster
- Dacron Mainsail, 2 Slab Reefs
- Genoa 135% by Sobstad (2013)
- Roller Furling Profurl NC 42 –genoa new seals 2017
- 135% Genoa Stobstad (2013)
- Storm Sail new
- Profurl Furling System NC-42 Stay sail
- Storm trysail – new, separate track on mast
- Windlass 2 - series 24 Prevailer gel (2013)
- House batteries – 2 – Prevailer 8D gel –(2013)
- Engine start - lead acid – series 27 (2016)
- Generator start – lead acid - series 27 (2016)
- 100 amp Ample Power alternator on Yanmar
- 225 Balmar Alternator driven by Kubota diesel (1223 hours - Oct 2018), spare Balmar on board
- Both alternators Controlled by Ample Power V-3 smart controller (spare V-3 on board)
- 525 watts –solar array with 3 separate Victron regulators ( one spare on board)
- AirX 30 AMP wind generator
- Xantrex/Heart 2500 watt inverter /100 amp charger
- Link 2000R controller and Monitor
- Rule 3700 auto/manual whale gusher 10 in cockpit
- Edson Crash pump under sole in aft cabin
- Yanmar is plumbed to pump bilge by turning 2 valves
- Jabsco Water puppy –for bilge nuisance water
- Bilge pump cycle counter on Rule 3700
- Rocna 55 pound on port roller with 210’ of 5/16th inch HT chain
- Danforth 22S Stern anchor, 20’ 5/16th inch HT chain,150 ‘ ½” nylon
- Danforth Dingy anchor
- Various snubbers and chafe gear
- Lighthouse 1501 stainless steel windlass with dual gypsy and drum
- Bruce 66 pound on starboard roller with 325” of 5/16th HT chain
Oyster White Hull deck, and topsides(Alwcraft 2000,#F8222); Teal boot stripe, water and cove lines (Alwcraft #F5252); Pearl Gray nonskid (Alwcraft #F1196). Seahawk Black Island 77 bottom, Cetol Gloss on outside bright work, Epifanes Satin on interior varnished surfaces. Note several underway photos show previous black cove and waterline which are now teal.
$114,900.00 USD
